Why Choose Our Highway Guardrail Systems?
High Impact Absorption
Q235B / Q355B Steel — Dissipates collision energy and prevents catastrophic lane crossover.
30+ Years Rust Resistance
550–1100 g/m² Zinc — 30+ years service life against extreme UV and salt spray.
Certified Safety Standards
AASHTO M180 & EN 1317 — Batch-tested tensile strength and crash containment.
Fast Modular Installation
Pre-Punched Standard Holes — Rapid installation and low-cost section replacement.
Technical Specifications & Standard Dimensions
| Parameter / Specification | Standard Option (Class A) | Heavy-Duty Option (Class B) | Custom Engineering |
| Profile Type | W-Beam (Two-Wave) | Thrie-Beam (Three-Wave) | Transition / Terminal Beams |
| Applicable Standards | AASHTO M180, EN 1317, JT/T 281 | AASHTO M180, EN 1317, AS/NZS 3845 | ASTM / Custom Municipal Specs |
| Raw Material | High-Tensile Steel Q235B | Heavy-Duty Steel Q355B / GR50 | Stainless Steel / Weathering Steel |
| Nominal Thickness | 2.67 mm (12 Gauge) / 2.74 mm | 3.43 mm (10 Gauge) / 4.0 mm | Up to 4.5 mm custom |
| Beam Dimensions | 4320 mm × 312 mm × 83 mm | 4320 mm × 506 mm × 83 mm | Custom length cuts available |
| Surface Finish | Hot Dip Galvanized / Powder Coated | Hot Dip Galvanized | Dual Anti-Corrosion Coating |
| Zinc Coating Thickness | ≥ 550 g/m² (80 μm) | ≥ 1100 g/m² (150 μm) | 600 – 1200 g/m² customized |
| Post Compatibility | C-post, U-post, Sigma, Round, I-beam | Flange / Embedded Posts | Wood / Concrete Bridge Posts |
Complete Highway Crash Barrier System Components
W-Beam & Thrie-Beam Panels
Standard 3810 mm effective length and 4320 mm overall length panels with high curvature consistency.
Guardrail Posts & Spacers (Blockouts)
C-Shape, H-Beam, Sigma, and round steel posts paired with shock-absorbing steel/composite offset blocks.
Terminal Ends & Transitions
Fishtail ends, bull-nose terminals, and flared end treatments for terminal impact cushioning.
Fasteners & Accessories
High-tensile splice bolts (M16x35/45, Grade 8.8), anti-theft nuts, flat washers, and high-intensity prismatic delineators / reflectors.
Versatile Road Safety Applications
Highways & Freeways
Central median barriers and shoulder edges to prevent high-speed lane departures and vehicle rollovers.
Mountainous & Winding Roads
Sharp curves, steep embankments, and hazardous cliffside protection where strong containment is crucial.
Bridges, Flyovers & Culverts
Heavy-duty transition barriers between rigid concrete parapets and semi-rigid highway guardrails.
Industrial & Commercial Facilities
Parking lots, warehouse perimeter protection, loading dock ramps, and factory perimeter safety barriers.
Strict Manufacturing Process & Third-Party Quality Inspection
We operate fully automated continuous roll-forming production lines with automatic punching and cutting units, ensuring sub-millimeter dimensional precision.
Mill Test Certificates (MTC) provided for steel grade, yield strength, and chemical composition.
Magnetic and chemical stripping tests per ASTM A123 / ISO 1461 to guarantee uniform zinc coverage.
Strict verification for tensile strength, elongation, and structural integrity during dynamic vehicle impact.
Frequently Asked Questions (FAQs)
The primary distinction lies in nominal steel thickness. Class A guardrails feature a nominal thickness of 2.67 mm (12-gauge, minimum 2.55 mm), making them the standard choice for general highways and arterials. Class B guardrails feature a heavier 3.43 mm thickness (10-gauge, minimum 3.28 mm), designed for high-risk zones, steep grades, and heavy commercial freight corridors.
Under standard rural or inland highway environments, a standard 550 g/m² (80 μm) galvanized layer provides 25 to 30 years of maintenance-free service. For coastal, industrial, or high-humidity tropical zones, we recommend heavy-galvanized coatings (≥1100 g/m² or powder-coated dual layers) to withstand continuous salt spray and chemical corrosion.
Yes. We provide precision factory-curved guardrail beams (both concave and convex radii from 1.5 m to 45 m) tailored to your engineering road drawings, eliminating dangerous on-site cutting and bending.
Standard W-beams are bundled into compact, strapped packs of 50 or 100 pieces using steel belts and wood runners to avoid zinc friction damage during sea transit. A standard 20-foot container (FCL) accommodates approximately 18 to 22 tons (approx. 900–1,100 pieces of 2.67 mm beams plus hardware).
Partner with a Trusted Highway Guardrail Manufacturer Today
Planning an upcoming roadway expansion or international highway project? Our engineering team provides free project take-offs, custom barrier specifications, and competitive FOB/CIF container quotes.
